Leading Innovations in Crystals and Oscillators
-
The Pletronics factory in Lynnwood, Washington, is also the headquarters and hub for our global sales and engineering network.
-
Our in-house production lines fill special customer needs. Many special crystals and oscillators are manufactured at the Lynnwood facility.
-
Our design capabilities plus manufacturing expertise bring new oscillator concepts to completion - fast!
-
Members of our Sales and Engineering teams brainstorm new ideas for better products and service.
-
Members of the Pletronics sales and administrative teams, plus factory trained field sales representatives throughout the world help serve our customers frequency control needs.
Pletronics' Featured Products
-
Pletronics Pronto Series Any Frequency, Leadtime in Days, not Weeks.
-
J Series Oscillator Pletronics J series Ultra-Ultra Low Jitter Oscillator.
-
OCXO Pletronics Latest Generation of OCXO's.
-
New CMOS Pronto Series
- Program to Any Frequency
- Fast Rise and Fall Time
- Low Jitter
- 1.5 MHz - 170 MHz
- 1.8V, 2.5V, 3.3V
- -10°C to +70°C standard
- -20°C to +70°C, -40°C to +85°C optional
-
J Series Ultra-Ultra Low Jitter Oscillator
- Employs FUND and 3OT Xtal "Direct Frequency" technology and Fast Rise and Fall times (dV/dT) for ultra-ultra low jitter performance
- 100fS typical jitter over 12KHz - 20MHz at 156.25MHz
- From ±20ppm OTR -40° to +85°C
- CMOS, PECL, LVDS and HCSL output logic option
- 1.8V, 2.5V, 3.3V options
- Ideal for 5G PHYs, Cloud & Edge Networks, FTTH, OPN
- Developed frequencies range from 1.5MHz to 156.25MHz
- 2.0x2.5.0mm, 2.5x3.2, 3.2x5.0mm & 5.0x7.0mm size ceramic SMD package
-
OCXO - New Products
- Standard Frequencies available from 5Mhz to 100Mhz and higher
- Stratum 2 & IEEE-1588 compliant versions available
- Standard Operating temperature; -40° to 85°C, -30° to 70°C, 0° - 70°C
- Sine wave and CMOS outputs signals
- Standard Temperature stabilities down to ±3ppb
- Application specific solutions down to ±1ppb
- Low g-sensitivity versions available for precision datacom systems
Over 40 Years In The Industry
"Be the best supplier of crystals and oscillators in the industry." That's as true today as when Pletronics was founded in 1979. Our goal is superior quality and superior service. We welcome you to contact us and talk with one of our extremely knowledgeable support staff. We look forward to providing the products you need.
